Page 36 - Rapco Catalog
P. 36
DE-ICE APPLICATION
RAPCO,inc.
Aircraft Manufacturer and Model # Propeller Model # De-Icer Wire Harness PN / Solid Block Modular Brush Brush Module PN Brush PN
Notes OEM PN Hub Extender PN OEM PN Block Assy. PN (Quantity) (Quantity)
M20M B3D32C417/82NRD-X C-40151 RAC40522-1 (1) &
with McCauley De-ice C-40521 RAC40522-2 (1)
with Lycoming TIO-540-AF1A
M20R Ovation 3A32C418/82NRC-X C-40151 RAC40256-1 (1) &
with McCauley De-ice C-40257 Assy. RAC40256-2 (1)
with Continental TSIOL-550-G Engine
Rocket M20L, M20M, M20R 3AF32C525/80VMFA-X RA2171-2 C-40151 RAB40189 (2)
with McCauley STC for McCauley De-ice C-40179 Assy.
with Continental TSIOL-550-A Engine
Partenavia / Vulcanair
P68 Observer HC-C2YK-2CUF 4E1639 RA1543-1 (2) &
wth Lycoming Engines HC-C3YK-2 RA1543-2 (1)
P68TC HC-B3TF-7A RA2142-1 RA2111U-ROD (3) RA1543-7 (3)
with Allison Engines
AP68TP HC-B3TF-7 4E2200-10 RA2192-2 RA2162-1 RA2111U-ROD (2) RA1543-7 (2)
with Allison Engines
Pilatus Britten-Norman - Also see Britten Norman
PC-6 HC-B3TN-3 4E1185-5 RA1989-2 4E1311-2 RA1543-1 (2) &
with Pratt & Whitney Engine 4E2200-10 RA2192-2 RA1543-2 (1)
RA2144-1 RA2111U-ROD (3) RA1543-7 (3)
PC-6/B1-H2,PC-6/B2-H2,PC-6B/B2-H4 HCD4N-3P 4E2271-10 RA2192-4 RA2144-2 RA2111U-ROD (3) RA1543-7 (3)
with Hartzell STC SA377CH
with Pratt & Whitney Engine
PC-7 HC-B3TN-3 4E2200-10 RA2192-2 RA2190-1 RA2111U-ROD (2) RA1543-7 (2)
with Pratt & Whitney Engine
PC-7MK ll HC-D4N-2 4E2271-10 RA2192-4 RA2144-2 RA2111U-ROD (3) RA1543-7 (3)
with Pratt & Whitney Engine
PC-9 HC-D4N-2 4E2271-10 RA2192-4 RA2144-2 RA2111U-ROD (3) RA1543-7 (3)
with Pratt & Whitney Engine
PC-12, PC-12/45, PC-12/47 HC-E4A-3D 4E3051-10 RA2460-4
with Pratt & Whitney Engine RA2460-4HD
Piper / The New Piper Aircraft, Inc.
PA-23 Apache HC-A2LXL-2 4E229-10 RA2192-2
PA-23-160 C2YK-2
Goodrich STC SA1-484
wth Lycoming Engines
PA-23-250 Aztec HC-A3XK-2 4E229-10 RA2192-2
with Goodrich STC SA1-485
with 14 Volt
wth Lycoming Engines
PA-30, -39 Twin Comanchee, HC-C2YK-2 4E1639 RA1543-1 (2) &
with Miller STC SA1151SW RA1543-2 (1)
PA-31 Navajo HC-E2YR-2 4E2271-10 RA2194-1 4E1350-2 RA1306-1 (3)
Non-Pressurized 4E1350-5 RA1543-2 (3)
Normal Rotation Propellers RA2146-1 RA2111U-ROD (3) RA1543-7 (3)
wth Lycoming Engines
PA-31 HC-E2YR-2 4E2271-10 RA2194-1 4E1350-2 RA1306-1 (3)
Non-Pressurized, 4E1350-5 RA1543-2 (3)
Normal Rotation Propellers RA2146-1 RA2111U-ROD (3) RA1543-7 (3)
wth Lycoming Engines
PA-31 BHC-3YR-2A 4E1350-2 RA1306-1 (3)
Non-Pressurized, RA1649 Hub Ext. 4E1350-5 RA1543-2 (3)
Normal rotation propellers / No Air Conditioning RA2146-1 RA2111U-ROD (3) RA1543-7 (3)
wth Lycoming Engines
PA-31, PA-31-350 HC-E3YR-2 (AF, ALF, 4E2271-10 RA2194-1 RA2146-1 RA2111U-ROD (3) RA1543-7 (3)
Non-Pressurized ATF, ALTF) 4E2200-10 (CR) RA2194-1
Normal rotation propellers / No Air Conditioning RA1649 Hub Ext. 4E1350-5 RA1543-2 (3)
Right prop / Air conditioning 4E1908-1(A/C) RA1543-1 (2) &
wth Lycoming Engines RA1543-2 (1)
PA-31 Series, PA-31-325, PA-31-350 HC-C4YR-2 4E1601-7 RA2067-1
Colemill STC's SA970SO, SA1151SO 4E1601-14 RA2067-3
Normal rotation propellers / No Air Conditioning 4E1188-7 (C/R) RA2067-1 4E1350-5 RA1543-2 (3)
Right prop / Air conditioning 4E1908-1(A/C) RA1543-1 (2) &
wth Lycoming Engines RA1543-2 (1)
For Reference ONLY. For installation eligibility see FAA-PMA supplement.
34
