Page 54 - Rapco Catalog

General Aviation Brake Components

Manufacturer Year / Serial Number Conv/Mod Wheel Brake Disc Brake Lining Linings Rivet or Shim Pressure Grease Seal
Model Notes Kit # Assembly Assembly Per Wheel Mounting Pin Insulators Plate
Diamond
DA20-AC, DA20-C1, Katana 40-78E RA164-24200 30-9D RA066-10600 2 RA105-00200
DA40, DA40F 40-414A RA164-24400 30-239A RA066-14100 2 RA105-00200 RA154-03000
DA42, DA42 NG, DA42 M-NG, Twin Star 40-75Z RA164-01501 30-52Z RA066-10500 4 RA105-00200 RA063-01100
Edgley - see Lavaux
ERCO Ercoupe - see Univair
Emair
MA-1B Diablo 1200 1978 and on 40-139 30-111 RA066-10800 8 RA105-00200 RA063-02500
RA073-02600
Fairchild - see Swearingen
FFA Flugzeugwerke Altenhein AG
AS202-18A4 Bravo 224 and on 40-97A RA164-02601 30-63A RA066-10500 2 RA105-00200 RA063-01200
Fletcher - see Pacific Aerospace
Forney Aircoupe - see Univair
Found Brothers
100 Centennial 40-75B RA164-01501 30-52 RA066-10500 4 RA105-00200 RA063-01100
GAF - (Australia) / Nomad
N22B, N22S 40-75T RA164-08300 30-52Q RA066-10500 4 RA105-00200 RA063-01100
N24A Nomad Heavy Duty 40-143 RA164-08200 30-129 RA066-06200 4 RA177-00300 RA068-01100 RA063-01100
General Avia (Italy)
F.20, F.201TP, Pegaso 40-75G RA164-01501 30-52P RA066-10500 4 RA105-00200 RA063-01100
F.22, Pinguino 40-151 RA164-08500 30-164 RA066-06200 2 RA177-00300 RA063-01200
F.1300 40-131 RA164-05700 30-96 RA066-06200 2 RA177-00300 RA068-01100 RA063-01100
Gippsland
GA8 40-75T RA164-08300 30-52N RA066-10500 4 RA105-00200 RA063-01100
Globe Swift
GC1A, GC1B Conversion Kit, 6.00-6 199-48 40-113C RA164-04300 30-79B RA066-10500 2 RA105-00200 RA063-01200
Great Lakes
2T-1A, 2T-1A-1, 2T-1A-2 40-113 RA164-04000 30-75 RA066-10500 2 RA105-00200 RA063-01200
Grob / Grob Werke GMBH
G103, G103C 40-97A RA164-02601 30-63A RA066-10500 2 RA105-00200 RA063-01200
G109 Series 40-78B RA164-01700 30-9 RA066-10600 2 RA105-00200
G115, -A, -B, -C 40-78B RA164-01700 30-9 RA066-10600 2 RA105-00200
G115-T 40-84 RA164-01900 30-41B RA066-10600 4 RA105-00200
G115-TA 40-84 RA164-01900 30-41B RA066-10600 4 RA105-00200
Grumann - see Grumann American or Ag Cat
Grumman American (Gulfstreem) American General, Commander- also see Rockwell International
AA-1, -1A, -1B , TR-2 Yankee / Trainer All models thru 1974 40-86A RA164-02000 30-55B RA066-10500 2 RA105-00200 RA063-01200
1975 and on 40-88C RA164-02000 30-56B RA066-10500 2 RA105-00200 RA063-01200
AA-5 Traveler All models thru 1974 40-86A RA164-02000 30-55B RA066-10500 2 RA105-00200 RA063-01200
AA-5A, -5B Cheetah / Tiger 1975 and on 40-88C RA164-02000 30-56B RA066-10500 2 RA105-00200 RA063-01200
GA-7 Cougar 40-90 RA164-02201 30-23B RA066-06500 (PP) 2 RA177-00300 RA068-02800
RA066-06200 (BP) 2 RA177-00300
Gulfstream - see Grumann American or Aero Commander
Hawker Beechcraft - see Beech
Helio
H-250, H-295, H391, H-395 Courier 40-75E RA164-01501 30-52A RA066-10500 4 RA105-00200 RA063-01100
40-75D RA164-03601 30-52N RA066-10500 4 RA105-00200 RA063-01100
40-75T RA164-08300 30-52N RA066-10500 4 RA105-00200 RA063-01100
6.50-8 Tire 40-98A RA164-02707 30-66A RA066-11000 4 RA105-00200 RA068-01700
Industeia Unidas SA (Mexico)
A-9B Sparrow / Quail 40-99 RA164-02800 30-41, -41B RA066-10600 4 RA105-00200
International Aviation (see Britten Norman)
KAI) Korea Aerospace Industries
KT-1 Woongbi Drive Key
PN: RA205-02900
Lake / Aerofab
LA-4 1963 and on 40-113X RA164-04000 30-75X RA066-10500 2 RA105-00200 RA063-01200
40-74, RA164-00700 30-51, -51B RA066-10600 4 RA105-00200
40-74B
Heavy duty option 40-418 30-241 RA066-10500 4 RA105-00200 RA063-01100
Note: Please confirm brake assembly number. Part numbers with ‘RA’ are Rapco products. For Reference ONLY. For installation eligibility see FAA-PMA supplement.
52
