P. 56
General Aviation Brake Components
Manufacturer Year / Serial Number Conv/Mod Wheel Brake Disc Brake Lining Linings Rivet or Shim Pressure Grease Seal
Model Notes Kit # Assembly Assembly Per Wheel Mounting Pin Insulators Plate
PAC 750XL 40-179A RA164-03006 30-182 RA066-10800 8 RA105-00200 RA068-02800 RA063-02500 RA154-03000
Pressure Plate Assy. > RA073-08500
Pressure Plate Assy. > RA073-08502
Lining upgrade 199-281 40-179A RA164-03006 30-182A RA066-15300 8 RA177-00300 RA068-02800 RA063-02500 RA154-03000
Pressure Plate Assy. > RA073-08500
Pressure Plate Assy. > RA073-08502
Partenavia - see Vulcanair or G.A.F.
Pilatus Aircraft Ltd
PC-12/47E 1231 thru 1257, 1258 on. 40-424 RA159-07400 30-244 RA109-03000 72 RA105-08701 & RA063-08400
PC-12, PC-12/45, PC-12/47, PC-12/47E With Cleveland Conv. 199-276 (rotor disc) (wear pad) RA105-02401 RA073-10100
OH Kit PN: RA199-575A Stationary Disc
Drive Key RA205-05201 RA232-03500
RA242-01800
Pilatus Britten-Norman - see Britten Norman
Piper / The New Piper Aircraft, Inc.
J-3 Cub Univair STC 40-60 RA164-06700 30-60, -60A RA066-10600 4 RA105-00200
PA-11 Cub Special Univair STC 40-60 RA164-06700 30-60, -60A RA066-10600 4 RA105-00200
PA-12 Super Cruiser Univair STC 199-231 40-60 RA164-06700 30-60, -60A RA066-10600 4 RA105-00200
PA-14 Family Cruiser Univair STC 40-60 RA164-06700 30-60, -60A RA066-10600 4 RA105-00200
PA-16 Clipper Univair STC 40-60 RA164-06700 30-60, -60A RA066-10600 4 RA105-00200
PA-18-150 Super Cub, 18-7609137 & on 40-60 RA164-06700 30-60, -60A, RA066-10600 4 RA105-00200
PA-18A-150 Super Cub -60B
PA-18 Super Cub Univair STC 40-60 RA164-06700 30-60, -60A RA066-10600 4 RA105-00200
PA-18 Super Cub 1.5" axles. Univair STC 199-231 40-84 RA164-01900 30-41, -41B RA066-10600 4 RA105-00200
PA-20 Piper Cub Univair STC 40-60 RA164-06700 30-60, -60A RA066-10600 4 RA105-00200
PA-20 Piper Cub 1.5" axles. Univair STC 199-231 40-84 RA164-01900 30-41, -41B RA066-10600 4 RA105-00200
PA-20/22 Piper Cub 1.5" axles. Univair STC 199-231 40-84 RA164-01900 30-41, -41B RA066-10600 4 RA105-00200
PA-22-108 Colt 40-28 RA164-00500 30-18 RA066-10600 2 RA105-00200
PA-22-125, -135, -150, -160 Univair STC SA91AL 199-276 40-28 RA164-00500 30-18 RA066-10600 2 RA105-00200
PA-20/22 Piper Cub 1.5" axles. Univair STC 199-231 40-84 RA164-01900 30-41, -41B RA066-10600 4 RA105-00200
PA-23-150 Apache 3080A - 3000-500 RA066-10600 4 RA105-00200
PA-23-160 Apache 3080A - 3000-500 RA066-10600 4 RA105-00200 RA154-03000
PA-23-235 Apache 27-1 thru 27-3737 3080B RA164-00206 37-200-2 RA066-10600 8 RA105-00200 RA068-01100
PA-23 Series Aztec Conversion Kit, 7.00-6 199-63 40-131 RA164-05700 30-96 RA066-06200 8 RA177-00300 RA068-01100 RA063-01100
PA-23-250 Aztec 27-3738 thru 3080D RA164-03206 37-200A RA066-06500 (PP) 4 RA177-00300 RA154-03000
27-7554137, RA066-06200 (BP) 4 RA177-00300
27-7554139,
27-7554141 thru
27-7554149
27-7554138 40-131 RA164-05700 30-96 RA066-06200 8 RA177-00300 RA068-01100 RA063-01100
PA-24-180Comanche SB7100 24-1 thru 24-3295 3070 (40-5) RA164-00900 3000-250 RA066-10600 4 RA105-00200
PA-24-250 Comanche SB7100 24-3296 thru 24-3306 3070 (40-5) RA164-00900 30-41, -41B RA066-10600 4 RA105-00200 RA154-03000
PA-24-260 Comanche SB7100 24-3307 and on 40-58 RA164-00900 30-41, -41B RA066-10600 4 RA105-00200 RA154-03000
40-84 RA164-01900 30-41B RA066-10600 4 RA105-00200
PA-24-400 Comanche 24-130 and on 40-90 RA164-02201 30-23 RA066-06500 (PP) 2 RA177-00300 RA068-02800 RA154-03000
RA066-06200 (BP) 2 RA177-00300
PA-25-235, Pawnee w/SB7100 25-1 thru 25-1999 3070 (40-5) RA164-00900 3000-250 RA066-10600 4 RA105-00200
PA-25-235 25-2000 thru 25-2136 40-61 RA164-01300 3000-250 RA066-10600 4 RA105-00200
PA-25-235B 25-2137 thru 25-4171 40-61 RA164-01300 30-41, -41B RA066-10600 4 RA105-00200
PA-25-235C, D 25-4172 thru 40-84A RA164-03300 30-41, -41B RA066-10600 4 RA105-00200
25-7656119
PA-25-260C, D 25-7656120 and on 40-84A RA164-03300 30-41B RA066-10600 4 RA105-00200
PA-28-140 Cherokee/Crusier 28-20002 thru 28-20520 40-28 RA164-00500 30-18 RA066-10500 2 RA105-00200
28-20521and on 40-86 RA164-02000 30-55 RA066-10500 2 RA105-00200 RA063-01200
1974 and on 40-86B RA164-02000 30-55 RA066-10500 2 RA105-00200 RA063-01200 RA154-03000
PA-28-150 Chreokee 28-1 thru 28-1760 40-28 RA164-00500 30-18 RA066-10600 2 RA105-00200
28-1761 and on 40-86 RA164-02000 30-55 RA066-10500 2 RA105-00200 RA063-01200
PA-28-151 Cherokee/Warrior All, 1974 and on 40-86B RA164-02000 30-55 RA066-10500 2 RA105-00200 RA063-01200 RA154-03000
PA-28-160 Chreokee 28-1 thru 28-1760 40-28 RA164-00500 30-18 RA066-10600 2 RA105-00200
28-1761 and on 40-86 RA164-02000 30-55 RA066-10500 2 RA105-00200 RA063-01200
PA-28-161 Cherokee/ Warrior II 7716001 and on 40-86B RA164-02000 30-55 RA066-10500 2 RA105-00200 RA063-01200 RA154-03000
PA-28-180 Cherokee/Archer 28-1 thru 28-1760 40-28 RA164-00500 30-18 RA066-10600 2 RA105-00200
28-1761 and on 40-86 RA164-02000 30-55 RA066-10500 2 RA105-00200 RA063-01200
1974 and on 40-86B RA164-02000 30-55 RA066-10500 2 RA105-00200 RA063-01200 RA154-03000
PA-28-181 Cherokee/Archer ll 28-7690001 and on 40-86B RA164-02000 30-55 RA066-10500 2 RA105-00200 RA063-01200 RA154-03000
PA-28-235 28-10003 thru 28-10486 40-58 RA164-00900 30-34 RA066-11100 2 RA105-00200
Cherokee 235/Pathfinder 28-10487 and on 40-86, RA164-02000 30-55 RA066-10500 2 RA105-00200 RA063-01200
40-86B RA164-02000 30-55 RA066-10500 2 RA105-00200 RA063-01200 RA154-03000
PA-28-236 Dakota 28-7911001 and on 40-86B RA164-02000 30-55 RA066-10500 2 RA105-00200 RA063-01200 RA154-03000
28-7911001 and on, HD 40-90A RA164-02300 30-65 RA066-10500 4 RA105-00200 RA063-01100
PA-28R-180 Cherokee/Arrow 180 28R-30005 thru 40-84 RA164-01900 30-41, -41B RA066-10600 4 RA105-00200
28R-7130005
28R-7130006 and on 40-86 RA164-02000 30-55 RA066-10500 2 RA105-00200 RA063-01200
1974 and on 40-86B RA164-02000 30-55 RA066-10500 2 RA105-00200 RA063-01200
1977 and on 40-86B RA164-02000 30-55 RA066-10500 2 RA105-00200 RA063-01200
PA-28R-200 Cherokee/Arrow 200 28R-35001 thru 40-84 RA164-01900 30-41, -41B RA066-10600 2 RA105-00200
28R-7135109
28R-7135110 and on 40-86 RA164-02000 30-55 RA066-10500 2 RA105-00200 RA063-01200
1974 and on 40-86B RA164-02000 30-55 RA066-10500 2 RA105-00200 RA063-01200
1977 and on 40-86B RA164-02000 30-55 RA066-10500 2 RA105-00200 RA063-01200
PA-28-201T, PA-28R-201, 40-86B RA164-02000 30-55 RA066-10500 2 RA105-00200 RA063-01200
PA-28RT-201, PA-28R-201T
Note: Please confirm brake assembly number. Part numbers with ‘RA’ are Rapco products. For Reference ONLY. For installation eligibility see FAA-PMA supplement.
